Engine | ||
Make | Caterpillar | |
Model | C6.6 Acert | |
Gross Power | 174 hp | 129.8 kw |
Net Power | 166 hp | 123.8 kw |
Displacement | 403 cu in | 6.6 L |
Torque Measured @ | 1400 rpm | |
Number of Cylinders | 6 | |
Net Torque | 596 lb ft | 808.1 Nm |
Operational | ||
Operating Weight | 44312.9 lb | 20100 kg |
Fuel Capacity | 102 gal | 386.1 L |
Cooling System Fluid Capacity | 8.5 gal | 32.2 L |
Engine Oil Capacity | 4 gal | 15.1 L |
Front Diff Fluid Capacity | 2.8 gal | 10.6 L |
Rear Diff Fluid Capacity | 3.7 gal | 14 L |
Hydraulic System Fluid Capacity | 71 gal | 268.8 L |
Alternator Supplied Amperage | 75 amps | |
Hydraulic System Relief Valve Pressure | 5076 psi | 34997.8 kPa |
Hydraulic Pump Flow Capacity | 77 gal/min | 291.5 L/min |
Oscillating Axle Angle | 9 degrees | |
Max Steering Angle | 35 degrees | |
Tire Size | 10.00-20 16PR, dual | |
Transmission | ||
Number of Forward Gears | 2 | |
Number of Reverse Gears | 2 | |
Max Travel Speed | 23 mph | 37 km/h |
Swing Mechanism | ||
Swing Speed | 10.5 rpm | |
Swing Torque | 33928 lb ft | 46000.2 Nm |
Buckets | ||
Reference Bucket Capacity | 0.97 yd3 | 0.74 m3 |
Minimum Bucket Capacity | 0.74 yd3 | 0.57 m3 |
Maximum Bucket Capacity | 2.1 yd3 | 1.6 m3 |
Boom/Stick Option (MEX) 1 | ||
Boom/Stick Option (MEX) 1 | VA Boom / stick 2.2m | |
Shipping Height of Unit | 10.4 ft in | 3170 mm |
Shipping Length of Unit | 29.1 ft in | 8870 mm |
Max Digging Depth | 18.9 ft in | 5750 mm |
Max Reach Along Ground | 29.4 ft in | 8970 mm |
Max Cutting Height | 31.9 ft in | 9710 mm |
Max Loading Height | 22 ft in | 6700 mm |
Max Vertical Wall Dig Depth | 10.6 ft in | 3220 mm |
Boom/Stick Option (MEX) 2 | ||
Boom/Stick Option (MEX) 2 | VA Boom / stick 2.8m | |
Shipping Height of Unit | 10.8 ft in | 3300 mm |
Shipping Length of Unit | 28.9 ft in | 8820 mm |
Max Digging Depth | 20.9 ft in | 6360 mm |
Max Reach Along Ground | 31.5 ft in | 9590 mm |
Max Cutting Height | 33.5 ft in | 10210 mm |
Max Loading Height | 23.6 ft in | 7190 mm |
Max Vertical Wall Dig Depth | 13 ft in | 3960 mm |
Boom/Stick Option (MEX) 3 | ||
Boom/Stick Option (MEX) 3 | One-piece Boom / stick 2.2m | |
Shipping Height of Unit | 10.5 ft in | 3190 mm |
Shipping Length of Unit | 29.1 ft in | 8870 mm |
Max Digging Depth | 18.7 ft in | 5700 mm |
Max Reach Along Ground | 29.5 ft in | 9000 mm |
Max Cutting Height | 28.7 ft in | 8760 mm |
Max Loading Height | 19.4 ft in | 5900 mm |
Max Vertical Wall Dig Depth | 9.4 ft in | 2880 mm |
Boom/Stick Option (MEX) 4 | ||
Boom/Stick Option (MEX) 4 | One-piece Boom / stick 2.8m | |
Shipping Height of Unit | 10.9 ft in | 3330 mm |
Shipping Length of Unit | 29.4 ft in | 8950 mm |
Max Digging Depth | 20.7 ft in | 6300 mm |
Max Reach Along Ground | 31.5 ft in | 9600 mm |
Max Cutting Height | 30.1 ft in | 9170 mm |
Max Loading Height | 20.6 ft in | 6270 mm |
Max Vertical Wall Dig Depth | 11.9 ft in | 3620 mm |
Dimensions | ||
Overall Width | 8.4 ft in | 2550 mm |
Overall Width - Outriggers Down | 12.5 ft in | 3820 mm |
Height to Top of Cab | 10.4 ft in | 3170 mm |
Wheelbase | 8.5 ft in | 2600 mm |
Ground Clearance | 1.2 ft in | 370 mm |
Tail Swing Radius | 8.2 ft in | 2500 mm |
Upper Structure Clearance | 4.2 ft in | 1280 mm |
