| দিন | সাপ্তাহিক | মাসিক | |
|---|---|---|---|
| নিয়মিত | ৳28,933 | ৳1,21,520 | ৳3,47,200 |
| কর্পোরেট | ৳21,699 | ৳1,06,330 | ৳3,35,200 |
|
+ ডেলিভারি রেইট & অপারেটর রেইট
|
|||
Demolition ready excavator rentals: when you rent a MITSUBISHI MS120-8 from RentCTG, it will come equipped with full cab guarding and a hydraulic thumb.
Power: The Mitsubishi 6D14C is a turbo charged engine with 153 hp @ 1800 rpm. It is U.S. EPA Tier 3 certified and is charge air aftercooled.
Versatile: The MS120-8 excavator rental is the upper echilon of the mid-range of the MS series excavator rentals from Case Construction. The MS120-8 thrives on job sites where careful movement is the only option, such as digging a swimming pool in a residential area. Operators have said it has the performance of a 20-metric-ton machine and a work envelope of a 7-metric-ton standard configuration excavator. A track shoe width of only 23.6 inches allows for the MITSUBISHI MS excavator rental to be maneuver in tight spaces very easily.
Hydraulics: ISO patttern pilot controls, position mode selector and power boost options on the hydraulics of the MS120-8 rental make it a superb choice for power and efficiency.
আমরা দ্রুত ডেলিভারি দিয়ে থাকি সব ধরনের রেন্টাল চট্টগ্রাম এবং এর আসেপাশে। আমাদের ডেলিভারি রেইট দেখুর আরো ডিটেলসের জন্য।
*equipped excavator rentals will relay error codes, cautions, maintenance items, fuel levels, and much more.
| ENGINE | |
| Emission Rating | Tier 3 |
| Engine make / model | Isuzu 4 HKIX |
| Net Power - hp (kW) | 153 (114.4) |
| Rated rpm - rpm | 1800 |
| Net Peak Torque - lbf / ft (Nm) | 454 (616) |
| Max speed - mph (kph) | 3.1 (5) |
| Max. Drawbar pull - lbf (kN) | 42039 (187) |
| UNDERCARRIAGE | |
| Track shoe width - inches (mm) | 23.6 (600) |
| Ground Pressure - Std. Pad - PSI (kPa) | 5.37 (34) |
| HYDRAULIC SYSTEM | |
| Main pumps total flow - gallons (US) / min (lt/min) | 100.3 (380) |
| Relief pressure, main - PSI (bar) | 4970 (343) |
| SWING SYSTEM | |
| Swing Speed - rpm | 10.6 |
| BOOM | |
| Boom length - ft/in (m) | 18 ft 8 in (5.7) |
| Arm length - ft/in (mm) | 9 ft 10 in (3000) |
| Arm breakout force, normal - lbf (kN) | 29230 (130) |
| Rating standard | ISO 6015 |
| WORKING RANGES | |
| Max. Dig Depth - ft/in (mm) | 22 ft (6700) |
| Reach at ground level - ft/in (mm) | 31 ft 11 in (9730) |
| Depth of 8' bottom - ft/in (mm) | 21 ft 5 in (6520) |
| Dump Height - ft/in (mm) | 26 ft 4 in (8020) |
| LIFTING CAPACITIES AT GROUND LEVEL | |
| Lift over end, 10' (3 050 mm) radius - lbs (kg) | 18569 (8423) |
| Lift over end, Max. reach - lbs (kg) | 6019 (2730) |
| Lift over side, 10' (3050 mm) radius - lbs (kg) | 18569 (8423) |
| Lift over side, Max. reach - lbs (kg) | 4617 (2094) |
| BUCKET | |
| Bucket breakout force, normal - lbf (kN) | not published |
| BLADE | |
| Blade std or opt | Standard |
| DIMENSIONS | |
| Tail Swing Radius - ft/in (mm) | 5 ft 8 in (1720) |
| Ground Clearance - inches (mm) | 18 (460) |
| WEIGHTS | |
| Operating Weight - lbs (kg) | 53793 (24400) |
এখানে ক্লিক করুন আরো স্পেসিফিকেশনের জন্য।
